Inverter Counter Chiller
A chilled prep-counter refrigerator holding +2 to +8 degrees Celsius, available in 2-door and 3-door models from 4 to 7 feet, plus a narrower 600 series. Runs an inverter compressor with R290 refrigerant for quieter, lower-cost operation.
The Berjaya Inverter Counter Chiller is a chilled prep-counter refrigerator built for kitchens that need reliable +2 to +8 degree Celsius holding at working height. The range runs from the compact 2DC4-IV-Z up to the 3DC7-IV-Z, spanning 2-door and 3-door configurations in 4, 5, 6 and 7 foot lengths, with an equivalent 600 series offering a narrower depth for tighter counter runs. Every model uses an inverter compressor and R290 refrigerant, so the variable-speed cooling and lower running cost apply across the whole line, not just the largest unit.
Inverter Counter Chiller specifications
| Model | 2 Door – 4′ 2DC4-IV-Z | 2 Door – 5′ 2DC5-IV-Z | 2 Door – 6′ 2DC6-IV-Z | 3 Door – 6′ 3DC6-IV-Z | 3 Door – 7′ 3DC7-IV-Z |
| Temperature °C (Celsius) | +2 to +8 | +2 to +8 | +2 to +8 | +2 to +8 | +2 to +8 |
| External Dimension (mm) | 1200 x 760 x 840 | 1500 x 760 x 840 | 1800 x 760 x 840 | 1800 x 760 x 840 | 2100 x 760 x 840 |
| Gross Volume (Litres) | 258 | 361 | 465 | 465 | 566 |
| Energy Consumption (kWh / Day)* | 0.8 | 1.1 | 1.3 | 1.3 | 1.3 |
| Energy Savings (kWh / Day)* | 2.4 | 3.2 | 4.0 | 4.0 | 4.5 |
| Energy Savings Up to (% / Year)* | 74.68 | 74.42 | 75.47 | 75.47 | 77.59 |
| Voltage/ Phase (V/ Ph) | 220 – 230V/ 1 | 220 – 230V/ 1 | 220 – 230V/ 1 | 220 – 230V/ 1 | 220 – 230V/ 1 |
| Frequency (Hz) | 50 / 60 | 50 / 60 | 50 / 60 | 50 / 60 | 50 / 60 |
| Cooling Capacity (W) | 221.5 | 221.5 | 221.5 | 221.5 | 221.5 |
| Wattage (W) | 156.3 | 182.3 | 176.2 | 176.2 | 176.2 |
| Ampere (A) | 1.25 | 1.5 | 1.42 | 1.42 | 1.42 |
| Refrigerant | R290 | R290 | R290 | R290 | R290 |
| Defrost System | Forced Air Circulation | Forced Air Circulation | Forced Air Circulation | Forced Air Circulation | Forced Air Circulation |
| Temperature Control | Digital | Digital | Digital | Digital | Digital |
| PVC Coated Shelving | 4 | 4 | 4 | 6 | 6 |
| Weight (kg) | 78.5 | 91.5 | 101.5 | 112 | 121.5 |
Available in 600 Series
| Model | 2 Door – 4′ 2DC4-600-IV-Z | 2 Door – 5′ 2DC5-600-IV-Z | 2 Door – 6′ 2DC6-600-IV-Z | 3 Door – 7′ 3DC7-600-IV-Z |
| Temperature °C (Celsius) | +2 to +8 | +2 to +8 | +2 to +8 | +2 to +8 |
| External Dimension (mm) | 1200 x 600 x 840 | 1500 x 600 x 840 | 1800 x 600 x 840 | 2100 x 600 x 840 |
| Internal Dimension (mm) | 629 x 419 x 597 | 929 x 419 x 597 | 1229 x 419 x 597 | 1529 x 419 x 597 |
| Gross Volume (Litres) | 157 | 232 | 307 | 382 |
| Voltage/ Phase (V/ Ph) | 220 – 230V/ 1 | 220 – 230V/ 1 | 220 – 230V/ 1 | 220 – 230V/ 1 |
| Frequency (Hz) | 50 / 60 | 50 / 60 | 50 / 60 | 50 / 60 |
| Refrigerant | R290 | R290 | R290 | R290 |
| Defrost System | Forced Air Circulation | Forced Air Circulation | Forced Air Circulation | Forced Air Circulation |
| Temperature Control | Digital | Digital | Digital | Digital |
| PVC Coated Shelving | 4 | 4 | 4 | 6 |
Frequently asked questions
Q1. What temperature range does the Inverter Counter Chiller hold?
The Inverter Counter Chiller holds +2 to +8 degrees Celsius across every model in the range, which is the correct band for chilled food storage at counter level.
Q2. What is R290 refrigerant and why does it matter?
R290 is a natural hydrocarbon refrigerant with a very low global warming potential compared with older synthetic gases. Berjaya CKE uses it across the Inverter Counter Chiller range, keeping the equipment ahead of refrigerant phase-down rules in Malaysia.
Q3. What does the inverter compressor actually change day to day?
It varies its speed with the load instead of switching on and off at full power. For the Inverter Counter Chiller that means a lower starting current, a quieter kitchen and steadier holding temperatures than a fixed-speed equivalent.
Q4. Why does the insulation thickness matter?
Thicker, high-density foam slows heat transfer from outside to inside, so the unit maintains a stable internal temperature with less strain on the cooling system.
Remarks:
* Energy Savings compared with Standard Model
* In-House Laboratory Testing Report
Disclaimer:
– Specifications and design are subject to change without prior notice.
– All product dimensions (L × W × H) are subject to a manufacturing tolerance of ±5 mm.
– Product photos are for illustration purposes only and may differ from the actual product.
Features
The features below explain how the Inverter Counter Chiller range keeps chilled prep space at a steady temperature while cutting the electricity bill compared with a standard fixed-speed unit.
- Inverter Compressor, low starting current, high energy efficiency and low acoustic level with variable-speed technology.
- Solid Door maintain the desired temperature inside the refrigerator, contributing to better energy efficiency.
- R290 Environmental friendly refrigerant. Faster heat transfer and lower compressor load deliver significant daily electricity savings.
- Insulation: 5.5–6 cm high-density foam insulation ensures stable, even cooling even in hot climates.
- Effective counter – balanced weight system self-closing door provides smooth, even, positive closure.
- Durable stainless steel exterior and interior, Full-length door handle.
- Automatic defrost system saves energy consumption and provide the shortest possible defrost cycle.
- Ventilated System assisted with fan to ensure homogeneous coolness in the storage space.
- High-density Cyclo-isopentane Polyurethane insulated body saves energy.
- Singapore MEPS Certified – 760 Series.
Accreditation Statement:
Our Upright and Counter Range are registered with the Singapore National Environment Agency (NEA) under the Mandatory Energy Labelling Scheme (MELS) and bear the official Energy Label for commercial storage refrigerators in Singapore.Additional models in this range are currently undergoing third-party verification and registration to meet the forthcoming Minimum Energy Performance Standards (MEPS)
