Inverter Rectangular Showcase (2 Tier)
Berjaya Inverter Showcase
Inverter Rectangular Showcase (3 Tier)
Description
| Model – 2 Tier – 3 Tier | – RS09C-IV-2T RS09C-IV-3T | – RS12C-IV-2T RS12C-IV-3T | – RS15C-IV-2T RS15C-IV-3T | – RS18C-IV-2T RS18C-IV-3T |
| Temperature°C (Celsius) | +2 TO +8 | +2 TO +8 | +2 TO +8 | +2 TO +8 |
| External Dimension (L x W x H) (mm) | 900 x 700 x 1350 | 1200 x 700 x 1350 | 1500 x 700 x 1350 | 1800 x 700 x 1350 |
| Gross Volume (Litres) | 365 | 500 | 636 | 771 |
| Energy Consumption (kWh) | 3.7 | 3.8 | 4.8 | 5.6 |
| Energy Savings (kWh / Day) * | 10.2 | 14.9 | 17.4 | 18.6 |
| Energy Savings Up to (% / Year) * | 73.38 | 79.68 | 78.38 | 76.86 |
| Voltage/ Phase (V / Ph) | 220 – 230V/ 1 | 220 – 230V/ 1 | 220 – 230V/ 1 | 220 – 230V/ 1 |
| Frequency (Hz) | 50 / 60 | 50 / 60 | 50 / 60 | 50 / 60 |
| Cooling Capacity (W) | 346 | 445 | 445 | 675 |
| Ampere (A) | 2.16 | 3.05 | 3.27 | 3.98 |
| Wattage (W) | 261.6 | 385.5 | 409.3 | 529.7 |
| Refrigerant | R290 | R290 | R290 | R290 |
| Defrost System | Forced Air Circulation | Forced Air Circulation | Forced Air Circulation | Forced Air Circulation |
| Weight (kg) – 2 Tier – 3 Tier | – 171 175 | – 212 216 | – 250 256 | – 295 300 |
* Energy Savings compared with Standard Model
* In-House Laboratory Testing Report
Features
Features
- Inverter Compressor, low starting current, high energy efficiency and low acoustic level with variable-speed technology.
- Double Layer Low E Heater Glass energy efficiency by reducing the amount of heat that enters
or leaves the fridge. - R290 Environmentally friendly refrigerant
- Automatic defrost system saves energy consumption and provide the shortest possible defrost cycle.
- Ventilated System assisted with fan to ensure homogeneous coolness in the storage space.
- High-density Cyclo-isopentane Polyurethane insulated body saves energy.
- Humidity up to 75%. It is recommended to use in air-conditioned space. If the ambient humidity is higher than 75%, glass door heaters can be optionally switched on to alleviate condensation issue.
