1DDF-IV-BB
2DDF-IV-BB
3DDF-IV-BB
Description
| Model – Black Body – White Body – Stainless Steel Body |
1 Door 1DDF-IV-BB 1DDF-IV-WB 1DDF-IV-SB |
2 Door 2DDF-IV-BB 2DDF-IV-WB 2DDF-IV-SB |
3 Door 3DDF-IV-BB 3DDF-IV-WB 3DDF-IV-SB |
| Temperature°C (Celsius) | -18 to -12 | -18 to -12 | -18 to -12 |
| External Dimension (L x W x H) (mm) | 635 x (710 + 20) x 2060 | 1260 x (710 + 20) x 2060 | 1880 x (710 + 20) x 2060 |
| Gross Volume (Litres) | 404 | 882 | 1367 |
| Energy Consumption (kWh) | 4.8 | 7.7 | 9.4 |
| Energy Savings (kWh / Day) * | 13.9 | 26.8 | 40.2 |
| Energy Savings Up to (% / Year) * | 74.33 | 77.68 | 81.05 |
| Voltage/ Phase (V / Ph) | 220 – 230V/ 1 | 220 – 230V/ 1 | 220 – 230V/ 1 |
| Frequency (Hz) | 50 / 60 | 50 / 60 | 50 / 60 |
| Cooling Capacity (W) | 675 | 939 | 1251 |
| Ampere (A) | 2.69 | 3.63 | 3.79 |
| Wattage (W) | 323.10 | 456.10 | 474.60 |
| Refrigerant | R290 | R290 | R290 |
| Defrost System | Electric Heater | Electric Heater | Electric Heater |
| PVC Coated Shelving | 5 | 10 | 15 |
| Weight (kg) | 97 | 153 | 215 |
* Energy Savings compared with Standard Model
* In-House Laboratory Testing Report
Features
Features
-
- Inverter Compressor, low starting current, high energy efficiency and low acoustic level with variable-speed technology.
- Three Layer Heater Glass energy efficiency by reducing the amount of heat that enters
or leaves the fridge. - R290 Environmentally friendly refrigerant
- Automatic defrost system saves energy consumption and provide the shortest possible defrost cycle.
- Ventilated System assisted with fan to ensure homogeneous coolness in the storage space.
- High-density Cyclo-isopentane Polyurethane insulated body saves energy.
- Humidity up to 75%. It is recommended to use in air-conditioned space. If the ambient humidity is higher than 75%, glass door heaters can be optionally switched on to alleviate condensation issue.
