Refrigerated Barline
Refrigerated Barline
Back to products
Low Boy Drawer Counter Chiller
Low Boy Drawer Counter Chiller

2 / 3 Deck Drawer Counter Chiller

Download Product Brochure

SKU: N/A Categories: ,
Description
Model –
2 Deck		2 Drawer
BS 2DR/C1165/2		4 Drawer
BS 4DR/C1850/2		6 Drawer
BS 6DR/C2535/2
Temperature °C+1 to +6+1 to +6+1 to +6
External Dimension (mm)1165 x 760 x 8401850 x 760 x 8402535 x 760 x 840
Gross Volume (L)279536795
Voltage/Frequency (V/ Hz)230v / 1 / 50Hz230v / 1 / 50Hz230v / 1 / 50Hz
220v / 1 / 60Hz220v / 1 / 60Hz220v / 1 / 60Hz
Cooling Capacity (W)71210141113
Wattage (W)361 – 399503 – 557513 – 567
Ampere (A)2.5 – 2.73.2 – 3.63.3 – 3.6
RefrigerantR134aR134aR134a
Defrost SystemForced Air CirculationForced Air CirculationForced Air Circulation
Number of Drawer246
No. of 1/1 Size Pan (Depth 150mm)4812
Weight (kg)98140194
Unit for 20ft Container20128
Unit for 40ft Container442616
Model –
3 Deck		3 Drawer
BS 3DR/C1165/3		6 Drawer
BS 6DR/C1850/3		9 Drawer
BS 9DR/C2535/3
Temperature °C+1 to +6+1 to +6+1 to +6
External Dimension (mm)1165 x 760 x 8401850 x 760 x 8402535 x 760 x 840
Gross Volume (L)279536795
Voltage/Frequency (V/ Hz)230v / 1 / 50Hz230v / 1 / 50Hz230v / 1 / 50Hz
220v / 1 / 60Hz220v / 1 / 60Hz220v / 1 / 60Hz
Cooling Capacity (W)71210141114
Wattage (W)361 – 399503 – 557513 – 567
Ampere (A)2.5 – 2.73.2 – 3.63.3 – 3.6
RefrigerantR134aR134aR134a
Defrost SystemForced Air CirculationForced Air CirculationForced Air Circulation
Number of Drawer369
No. of 1/1 Size Pan (Depth 65mm)61218
Weight (kg)125197219.5
Unit for 20ft Container20128
Unit for 40ft Container442616
Features

Features

  • Tested at ambient temperature of 38°C
  • Ideal for food storage.
  • Self-closing drawers provide convenient refrigerant storage.
  • High-density Cyclo-isopentane Polyurethane insulated body saves energy.
  • Refrigeration system protected from corrosion by urethane-treated evaporator coil.
  • Environmentally friendly refrigerant (CFC and HCFC Free) R134a
