Spiral Mixer - Manual Control ( 1 Speed)
Spiral Mixer - Manual Control (2 Speed)
Spiral Mixer - Digital Control (2 Speed)
Description
| Model : 50Hz Model : 60Hz | BJY-SM30M BJY-SM30M60 | BJY-SM40M BJY-SM40M60 | BJY-SM50M BJY-SM50M60 | BJY-SM30D – | BJY-SM40D – | BJY-SM50D – |
| Speed and Control | 1 Speed Manual Control | 2 Speed Manual Control | 2 Speed Manual Control | 2 Speed Digital Control | 2 Speed Digital Control | 2 Speed Digital Control |
| Bowl Capacity (Litres) | 28 | 45 | 66 | 28 | 45 | 66 |
| Voltage / Phase (V/Ph) | 220-240 / 1 | 380-415 / 3 | 380-415 / 3 | 380-415 / 3 | 380-415 / 3 | 380-415 / 3 |
| Input Power (W) | 1700 | 1200 / 1800 | 2800 / 3600 | 1300 / 1700 | 1200 / 1800 | 2800 / 3600 |
| Mixing Speed (R/min) | 230 | 240 / 120 | 240 / 120 | 230 / 150 | 240 / 120 | 240 / 120 |
| Bowl Speed (R/min) | 20 | 24/12 | 24/12 | 20/13 | 24/12 | 24/12 |
| Max Dough Capacity (Kg) | 12.5* | 20* | 25* | 12.5* | 20* | 25* |
| Machine Dimension (mm) | 450 x 730 x 850 | 500 x 900 x 1200 | 600 x 1000 x 1230 | 430 x 850 x 940 | 490 x 930 x 1160 | 590 x 1020 x 1170 |
| Packing Dimension (mm) | 920 x 560 x 1030 | 1010 x 580 x 1300 | 1120 x 710 x 1500 | 910 x 550 x 1040 | 1110 x 590 x 1290 | 1110 x 640 x 1290 |
| Weight (Kg) | 167 | 256 | 275 | 167 | 256 | 275 |
* Max Dough Capacity means maximum weight after flour pre-mixed with 50% of water.
Features
Features
- High efficiency motor.
- Able to gently mix the bread dough, develop proper gluten structure and not overworking the dough
- Commonly used for mixing bread dough.
- Capable to handle a variety of different dough types such as very stiff dough with low hydration levels and high hydration dough types such as ciabatta.
